Gantry Crane with Grab

Capacity:10~500T
Span:16~40m
Lifting height: 3~34m
Lifting speed: 4.62,6.25,7.68,9.28,19.8m/min

Apply: Gantry Crane with Grab Bucket contains main beam system, crab system, grab system, and power supply system. This crane is widely used in mine, port, factory, workshop, warehouse, and goods yard etc.

Get A Free Quote more

HOT PRODUCTS

U-Shaped Double Girder Gantry Crane

Double Girder Gantry Crane

Truss Gantry Crane

European Semi-Gantry Crane

Description
Specifications
Features

Gantry Crane with Grab Bucket contains main beam system, crab system, grab system, and power supply system. This crane is widely used in mine, port, factory, workshop, warehouse, and goods yard etc to load and unload materials. the grab can be mechanical type, also can be electric hydraulic type, you can choose it or you tell us your working conditions and our engineers will recommend you the suitable according to your actual situation.

apacity	Main	t	50		75	100	200	320	400	500
apacity	Aux	t	10		20	20	32	50	30	80
Span		S(m)	30	35	40	16	22	18	18	28.5
Lifting height	Main	m	Above rail max.22		22	16	12	13	18	3 3/10
Lifting height	Aux	m	Above rail max.24		22	17.5	13	14	20.0	34.0
Lifting speed	Main	m/min	7.68		6.25	4.62	0.2-1.8	0.14-1.4	0.15-1.5	0.15-1.5
Lifting speed	Aux	m/min	19.8		9.28	9.28	6	7.5	6	0.6-6
Trolley speed		m/min	38.6		38.9	13.1	20	7	10	1.36-13.6
Crane speed		m/min	42.7		38.9	17.8	16	17	18	1.6-16
Work duty			A5		A5	A5	A5	A5	A5	A5
Track			QU 80			QU 100	QU 120

1. Quality problems of products sold by our company will be solved as per the “three guarantees” system of our company by the “three guarantees” service team;

2. Related personnel will be sent to the site immediately after receiving quality complaints (by call, letter or oral notice) from clients;

3. Personnel involved in after-sales service shall be serious and considerate in handling the problem to make clients care-free;

4. In addition to solve quality problems, personnel involved in after-sales service shall train clients, answer their technical inquiries and related questions free of charge;

5. Related cost for products with quality problem will be shouldered by our company. Our company charges for quality problems caused by clients (or problems after the warranty term), but the charge will not be higher than the expense (or cost);

Develop your lifting solution
