Electric Hydraulic Orange Petal Grab

Model Number:DYZ
Type:Electro hydraulic grab bucket
Electricals:Siemens Brand
No. of tines: Five or six on your option

Apply: Electric Hydraulic Orange Petal Grab Type: Electro hydraulic grab bucket; Electricals: Siemens Brand; No. of tines: Five or six on your option; Usage: scrap metal,waste iron, ores, pig iron

Get A Free Quote more

HOT PRODUCTS

Light Duty Wheel

Double Rope Grab

Clamp for Steel Billet

End Carriage

Description
Specifications
Features

Model Number: DYZ

Type: Electro hydraulic grab bucket

Electricals: Siemens Brand

No. of tines: Five or six on your option

Usage: scrap metal,waste iron, ores, pig iron

Attention: Forbid used in water

Power: Hydraulic

Hydraulic Pressure: 20~25 Mpa

Oil tank: High capacity with enough hydrauilic

Power Method: Flexible Cable

Volum: 3 m3,4 m3,5 m3,10 m3

Type	Density	Volume	Grab Weight	Power KW	Open and close time	Capturing the material	Crane SWL
Type	t / m3	m3	t	380V 50Hz	s	t	t
DYZ0305	1.8	0.5	1.1	7.5	5/7	0.9	3
DYZ0306	1.7	0.6	1.15	7.5	5.5/7.5	1.02	3
DYZ0507	3	0.75	2.5	15	8/12	2.25	5
DYZ0510	2	1	2.8	15	9/13	2	5
DYZ0515	1.2	1.5	2.6	13	10/15	1.8	5
DYZ0815	2.7	1.5	3.1	18.5	5/8	4.05	8
DYZ1020	2.5	2	4.5	18.5	5/8	5	10
DYZ1030	2	3	3.85	22	6/10	6	10
DYZ1540	2	4	5.3	22	6/10	8	15
DYZ1650	1.5	5	6.4	27	8/13	7.5	16
DYZ1630	2.5	3	6.9	27	8/14	7.5	16
DYZ2042	2.8	4.2	8.43	30	9/15	11.8	20
DYD71-50		0.34	1.105	7.5	5/7		2.0-3.0
DYD71-60		0.42	1.140	7.5	5.5/7.5		2.0-3.0
DYD85-160		1.6	2.55	18.5	5/8		8-10
